ZXAIEC43A Getting Started Guide

  • ZXAIEC43A
  • esp32c3
  • GX8006A
2025-11-13
Update history
Date Version Author Update content
2025-11-13 1.0.0A Hades First release

1. Network Configuration Process

  1. Ensure the device is powered correctly. Once powered on, it will prompt: “I’m Xiao Ming, nice to meet you.”
  2. If Wi-Fi has already been configured, you must unbind the device (press the button 6 times quickly) before configuring the network again.
  3. When the voice prompt says “Device not bound, please use the app to bind”, open the mini program “GS AI Hardware Agent” (QR code at the bottom of this document) to bind the device.
  4. In GS AI Hardware Agent, tap the “+” button in the bottom-right corner, select Bluetooth Network Configuration, choose your device, and follow the on-screen instructions to complete the binding process.

2. Voice Interaction Instructions

  1. Usage environment: Ensure the device is powered and successfully connected to the network.
  2. Wake word: “Hello, Xiao Ming.”
  3. During conversation: You may interrupt the conversation directly without using the wake word; however, during music playback, you must use the wake word to interrupt.
  4. New conversation: After a conversation ends, you must wake the device again to start a new one.

3. Voice Prompts – General

Function Action Voice Prompt
Power On Power applied I’m Xiao Ming, nice to meet you
Power On (Unbound) Unbound state Device not bound, please use the app to bind
Network Connected Network normal Network connected, come chat with me
Network Error Wi-Fi not found / error Server connection failed, please check network
Wake “Hello, Xiao Ming” Hi there / I’m here / What’s up
End of Conversation 30s silence trigger I had a great chat with you, see you next time

4. Voice Prompts – Network

Function Action Voice Prompt
Device Not Configured Unbound state Device not bound, please use the app to bind
Incorrect Wi-Fi Password Enter wrong password The Wi-Fi password seems incorrect, try again
Wi-Fi Not Found 5G Wi-Fi or nonexistent network The Wi-Fi you entered was not found
Wi-Fi Connection Failed Multiple failures during setup Wi-Fi connection failed, try another one
Configuration Success Setup complete Awesome! Wi-Fi connected successfully
Network Error After Setup Wake-up action Server connection failed, please check network

5. Voice Prompts – OTA

Function Action Voice Prompt
OTA Start New firmware detected at startup OTA update starting, let's chat later
OTA Failure OTA update failed Something went wrong, please restart and try again
OTA Success OTA completed Great! Update completed

6. Voice Prompts – Voice Commands

These features require an active network connection.

Function Action Voice Prompt
Adjust Volume Commands containing “volume”, “sound”, “increase”, etc. e.g. “Turn volume to 50%” Volume set to 50
Exit Conversation Commands like “exit”, “stop talking”, “stand down” I had a great chat with you, see you next time

7. LED Indicator Description

LED Color State Meaning
Red Flashing Device not paired
Red Breathing Device not connected to network
Red Solid Device error / OTA failure
Red → Yellow Gradient Connecting to network
Purple Solid Standby mode
Purple → Cyan Gradient In conversation, recording state
Purple → Blue Gradient In conversation, playback state
Blue Breathing OTA in progress
Green Solid OTA update successful

8. Button Functions

Function Action Description
Unbind Press 6 times quickly Unbind the device; after reboot, prompts “Device not bound…”
Force Exit Conversation Short press during conversation Forces exit; prompts “I had a great chat with you…”

9. Usage Guidelines

  • Power Requirement: Powered via standard USB Type-C.
  • Network Requirement: Supports 2.4GHz Wi-Fi only.
  • Adding Smart Device: Ensure Bluetooth positioning is enabled and authorized, then add the device in the mini program using “Bluetooth Network Configuration.”
  • Device Not Found: If the device cannot be detected, perform the unbind procedure (voice prompt: “Device not bound, please use the app to bind”).

QRCode
